Specification
| Type | Diameter（mm） | Length（mm） | |||
| Nominal | Allowed Tolerance | Nominal | Allowed Tolerance | ||
| SF×BN | 55,60,65,70,75 80,85,90,100 |
+2.00 0 |
100
1000 300 |
+5.0
+2.50 +2.0 |
|
| 110,120,130 140,150 |
+2.50 0 |
||||
| SF×BN | 180,200,250 270,300 |
+3.0 0 |
1000
300
|
+2.50
+2.0
|
|
(The Main Technical Indexes)
| Item | 单位Unit | 指标Result |
| Apparent density | g/cm3 | 2.10-2.30 |
| Tensile strength ≥ | MPa | 14.0 |
| Tear elongation ≥ | % | 140 |
Notes: when the diameter ≥ 16 mm, only test the apparent density
Application
Electrical insulating parts, sealing gasket, anti adhesion materials.
