PTFE Extruded Rod

There are 3 kind of PTFE rod. Diameter 4-9 mm rod was made of 100% PTFE by paste extrusion processing; diameter 10-50 mm was made by great use Teflon resin suspended by the plunger extrusion processing; diameter more than 50 mm is made by molded process.

In the known plastic, PTFE has the most excellent chemical resistance and dielectric performance, non-aging, not sticky, in no load cases it may be used at -180℃～+260℃, in known solid material it has minimum friction coefficient.

Quote Now

Quote Now






    Category:



    Specification

    Type

    		 Diameter（mm）  Length（mm）
    Nominal Allowed Tolerance Nominal Allowed Tolerance
    SFFBN 4,5,6 +0.48 100 +5.0
    7,8,9 +0.58
    SF×BN 10,13,15,16,18 +1.10 1000 +3.60
    20,25,30 +1.30
    35,40,45,50

    +1.60





    (The Main Technical Indexes)

    Item Unit Result
    Apparent density g/cm3 2.10-2.30
    Tensile strength ≥ MPa 14.0
    Tear elongation ≥ % 140

    Notes: when the diameter ≥ 16 mm, only test the apparent density

    Application

    Electrical insulating parts, sealing gasket, anti adhesion materials.
